About

The Lager packs a quality punch with a butted top tube and down tube, Cr-Mo seat tube, alloy cranks, and super smooth Freedom ThickSlick tires. The perfect bike to get you where you want to go and in style.

Key Features

Hi-Ten steel urban single-speed style frame with butted top tube and down tube, Cr-Mo seat tube with integrated seat clamp, plus water bottle and fender mounts for increased carrying capacity
Hi-Ten SE steel straight leg fork with wide tire clearance
Dual pivot alloy brakes
Alloy cranks with sealed cartridge Euro bottom bracket
SE high-flange alloy fixed/free 36H hubs with extra high-profile double-wall rims

SPECIFICATIONS

SIZES	49cm, 52cm, 55cm, 58cm
COLOR(S)	Black, Blue
FRAME	Hi-Ten Urban Single Speed, Butted Top Tube and Down Tube, Cr-Mo Seat Tube, Integrated Seat Clamp, Water Bottle & Fender Mounts
FORK	Hi-Ten SE Straight Leg w/ Fender Mounts
CRANKSET	SE Alloy, Cartridge BB, 46T Chainring
PEDALS	Resin Platform
CHAIN	KMC Z410A
WHEELSET	SE High-flange Alloy Fixed/Free 36H Hubs w/ High-profile Double-wall Rims, 17T Freewheel & 17T Fixed cog
TIRES	Freedom ThickSlick Sport 700 x 28c
BRAKESET	Alloy Dual Pivot Caliper Front & Rear
BRAKE LEVERS	2-Finger Alloy Lever Front & Rear
HEADSET	Tange 1-1/8" Threadless
HANDLEBAR	SE Alloy Riser 580mm Wide
STEM	SE Alloy, 7 Degree Rise, 25.4mm Clamp
GRIPS	SE Urban Mushroom Grips w/ SE Rubber End Plugs
SADDLE	SE Urban
SEATPOST	SE Micro Adjust Alloy, 27.2mm
ACCESSORIES	Two Styles of Handlebars Included: SE Alloy Riser & SE Alloy Bullhorn, SE Cable Clips
WEIGHT	26.02 lbs / 11.80 kgs

*Specifications subject to change without notice

GEOMETRY

	BIKE SIZE	49cm	52cm	55cm	58cm
	SIZE	XS	S	M	L
A	SEAT TUBE, CENTER TO TOP	490	520	550	580
B	TOP TUBE, EFFECTIVE	553	562	573	580
C	HEAD TUBE LENGTH	90	95	125	155
D	SEAT TUBE ANGLE	74°	74°	74°	74°
E	HEAD TUBE ANGLE	72°	72°	72°	72°
F	CHAINSTAY LENGTH	420	420	420	420
G	WHEELBASE	1006	1016	1028	1036
H	BOTTOM BRACKET DROP	58	58	58	58
I	STANDOVER	758	775	802	833
	STEM	65	65	80	90
	HANDLEBAR WIDTH	580	580	580	580
	CRANK	165	165	170	170
	WHEEL SIZE	700c	700c	700c	700c
	SEAT POST DIAMETER	27.2	27.2	27.2	27.2
